Main technical parameters:
optimum winding diameter: Φ 0.30 ~ Φ1.0 mm
rotor diameter: Φ23 ~ Φ40mm
rotor stack thickness: 10 to 50 mm
rotor slot number: 3 tank / 5/7 slots
commutator diameter:Φ7.5 ~ Φ25 mm
fly fork speed: 0 ~ 3000 RPM
air: 0.5 ^ 0.7 MPa
power: 380 vac / 50 hz
machine power: 3.5 KW
Special specifications can be customized
Service hotline： 0755-23468502 / 27155162
Functions and Features
It is suitable for the rotor with thick diameter. The rotor can be wound independently in double position and adjustable
Multi-stage tension can be set
Adopt the auxiliary hook of the hanger
The data can be stored and called
The winding mould can be changed quickly
